CAK5085数控车床

技术参数

Specifications

CAK5085

床身最大工件直径

Max .Swing over bed

500mm

刀架上最大回转直径

Max.swing over arriagemm

250

最大工件长度

Max. Work piece Length

1000mm

主轴孔锥度

Spindle taper

MT6(Φ90 1:20)

卡盘规格

Chuck size

C6 (D8)

主轴通孔直径

Thru-hole of spindle

52mm(80mm、105mm)

转速范围

Spindle speeds

21-1600rpm(独立主轴）

(I 162-1500 II 66-500 III 21-150)

尾座顶尖行程

Tailstock center sleeve travel

150mm

尾座套筒锥度

Tailstock center sleeve taper

MT5

重复定位精度

Repeatability error

0.01mm

快移速度

X/Z rapid traverse

3/6m/min

刀柄尺寸

Tool shank sizemm

25×25

床身宽度

Bed width

400mm

电机功率

Spindle motor

7.5kw

包装尺寸

Packing dimensions

(L×W×H mm)

Overall dimensions for 750

2440×1450×1900mm

Overall dimensions for 1000

2650×1450×1900mm

Overall dimensions for 1500

3150×1450×1900mm

Overall dimensions for 2000

3610×1450×1900mm

Overall dimensions for 3000

4610×1450×1900mm

重量

Weight(kg)

Length

毛重G.W. 净重N.W.

毛重G.W. 净重N.W.

Overall dimensions for 750

2800/2100

2900/2120

Overall dimensions for 1000

2900/2200

3000/2240

Overall dimensions for 1500

3150/2300

3200/2350

Overall dimensions for 2000

3350/2700

3400/2740

Overall dimensions for 3000

4100/3500

4200/3600
